Hager placa de entrada de cables WTA6200BG, negro brillante, 12 orificios precortados, M20/M25/M32

Conduit entry plate for Hager Volta and Golf distribution boards, providing a snap-in solution for cable entry and strain relief with 12 pre-punched knock-outs for M20, M25, and M32 conduits.

Advantages

The glossy black plate is made of halogen-free plastic and features a snap-in mounting for quick installation without tools. It maintains a clean appearance while offering flexible cable routing options.

Suitable for

• Hager Volta series distribution boards
• Hager Golf series consumer units
• Indoor electrical installations requiring conduit entry

Key specifications

• Number of cable entries: 12 (pre-punched / knock-out)
• Compatible conduit sizes: M20, M25, M32
• Max. conduit diameter: 32 mm
• Material: Plastic, halogen-free
• Colour: Black, glossy finish
• Mounting type: Snap-in / clip-on
• Glow-wire test temperature: 650 °C
• Operating temperature range: -5 °C to 60 °C
• Module width: 100 mm, depth: 10 mm

Recommendations

Select the appropriate knock-outs based on the conduit size and cable diameter to ensure proper strain relief and maintain the IP30 protection level of the enclosure.
