HELUKABEL HELU F-C-PUR-JZ 5G0,5 21203 - Cable de control PUR apantallado 5 x 0,5 mm², gris

In automated production lines where cable carriers flex millions of times, the HELUKABEL HELU F-C-PUR-JZ 5G0,5 21203 keeps control circuits intact. Its five fine-wire copper conductors and tough PUR sheath withstand constant motion, oil splash, and UV exposure without cracking or signal loss.

Key specifications

• 5 cores, 0.5 mm² each, fine-wire stranded (Class 5) bare copper
• Core identification: black with white numbers plus green-yellow earth
• PVC core insulation, grey (RAL 7001) PUR outer sheath
• Tinned copper braid shielding, approx. 85% coverage
• Rated voltage 300/500 V, test voltage 3000 V
• Outer diameter approx. 7.1 mm, weight approx. 68 kg/km
• Temperature range: -30 °C to +80 °C flexing, -40 °C to +80 °C fixed
• Minimum bending radius: 10 x cable diameter (flexible)
• Flame retardant per IEC 60332-1-2, excellent oil resistance, good UV resistance

Why choose it

The PUR jacket delivers superior abrasion and chemical resistance compared to standard PVC, extending service life in harsh industrial environments. The tinned copper braid provides reliable EMI protection, while the fine-wire stranding ensures flexibility for continuous movement in drag chains and robotic applications.

Ideal use cases

• Control and signal transmission in machine tools and conveyor systems
• Cable tracks, drag chains, and moving machine parts
• Industrial plants with exposure to oils, coolants, and UV light
• Outdoor installations requiring weather-resistant cabling

Good to know

This cable is part of the HELU F-C-PUR-JZ series, known for its robust construction and compliance with international standards. It is supplied in bulk lengths; contact your distributor for cutting options. Always follow local regulations for installation and grounding.
