LANVIEW Quick Assembly Flat Pack 19 - Armario de red de pared 6U, 600x500x370mm, Negro

Finding the right enclosure for network equipment in a space-constrained environment can be tricky. This LANVIEW 19-inch wall-mount cabinet offers a sturdy and secure housing for your patch panels, switches, and other rack-mount devices. Thanks to its clever flat-pack design, it assembles in minutes without sacrificing strength or stability.

Who is it for

This cabinet is a perfect fit for IT installers, small businesses, home offices, and anyone who needs to organise networking gear on a wall. It keeps equipment off the floor, reducing clutter and improving airflow. The compact 6U height is ideal for smaller installations while providing enough space for essential active components.

Main features

• Quick assembly flat pack design reduces installation time and simplifies transport
• Tempered glass front door with key lock deters unauthorised access and provides a clear view of equipment status LEDs
• Adjustable front and rear 19-inch mounting rails accommodate various equipment depths
• Cable entry points on top and bottom with brush strips keep cables organised and prevent dust infiltration
• Removable and lockable side panels allow easy access for cabling and maintenance
• Fan-ready top panel supports optional active cooling to maintain optimal operating temperatures
• Durable cold-rolled steel construction with powder coated finish ensures long-lasting protection

Specifications

• Rack size: 19 inch, 6U
• External dimensions: 600 mm width x 500 mm depth x 370 mm height
• Usable depth: approximately 450 mm
• Material: Cold rolled steel
• Static load capacity: 60 kg
• Protection rating: IP20
• Colour: Black (RAL 9005)
• Compliance: RoHS, CE

Tips

When mounting, ensure the wall structure is capable of supporting the cabinet's full load. Adjust the rear mounting rails to match your equipment depth for a perfect fit. For better airflow, consider installing an optional fan in the top panel. Always secure the door lock after installation to prevent unauthorised access.
