Sommer Cable SC-Vector 0.8/3.7 Cable de conexión de vídeo HD-SDI, conector macho BNC a conector macho BNC, 1 m, negro

Signal integrity is the backbone of professional video, and a weak link in the chain can ruin a broadcast. The Sommer Cable SC-Vector 0.8/3.7 HD-SDI Video Patch Cable eliminates that risk with precision 75-ohm impedance and robust shielding, delivering pristine HD-SDI, 3G-SDI, 6G-SDI, and even 12G-SDI signals over short runs. Built for studio patch bays, OB vans, and post-production suites, this 1-meter cable ensures your video feeds stay clean and reliable.

Who is it for

Broadcast engineers, video technicians, and AV integrators who demand dependable coaxial connections for HD-SDI infrastructure. Ideal for patching cameras, routers, monitors, and recorders in professional environments.

Main features

• 75-ohm impedance with gas-injected PE dielectric for stable signal transmission
• Dual-layer shielding: AL/PT foil plus 95% copper braid to reject EMI/RFI
• BNC male connectors on both ends for secure, quick connections
• Supports HD-SDI, 3G-SDI, 6G-SDI, and 12G-SDI (distance dependent)
• Flexible PVC jacket with 6.0 mm outer diameter for easy routing

Specifications

• Cable type: Coaxial video patch cable (SC-Vector 0.8/3.7)
• Length: 1 m
• Connectors: BNC male to BNC male
• Impedance: 75 Ω
• Conductor: Bare copper, 0.80 mm (AWG 20)
• Dielectric: Gas-injected PE, 3.70 mm diameter
• Shielding: AL/PT foil + copper braid (95% coverage)
• Jacket: PVC, 6.00 mm diameter, black
• Capacitance: 52 pF/m
• Velocity of propagation: 82%
• Attenuation at 1 GHz: 18.5 dB/100 m
• Return loss (0.1–200 MHz): >30 dB
• Operating temperature: -30 °C to +70 °C

Tips

For best performance, keep cable runs as short as possible and avoid sharp bends. Use in patch bays with proper strain relief to maintain connector integrity.
