TELEGÄRTNER H02082A0015 Cable de fibra óptica 4x LC OM3 multimodo, 50 m, LSZH, blanco

High-density fibre installations demand reliable connectivity without sacrificing space. The TELEGÄRTNER H02082A0015 addresses this by combining four OM3 multimode fibres into a single 50-metre cable, terminated with LC/PC connectors on both ends. This design reduces cable clutter while maintaining the performance needed for 10G Ethernet and high-speed data links.

Who is it for

Network engineers and data centre technicians who need a robust, multi-fibre patch cable for backbone or distribution runs. It suits environments where low smoke and zero halogen emissions are required, such as offices, schools, and public buildings.

Main features

• Four OM3 multimode fibres (50/125 µm) in one cable
• LC/PC connectors on both ends (4x LC to 4x LC)
• 50-metre length for extended reach
• White LSZH jacket for safety and easy identification
• Optimised for 850 nm and 1300 nm wavelengths

Specifications

• Cable length: 50 m
• Fibre type: Multimode OM3
• Core/cladding diameter: 50/125 µm
• Connector type: LC/PC (4 connectors each end)
• Jacket material: LSZH
• Jacket colour: White
• Insertion loss: max 0.3 dB per connector
• Return loss: min 30 dB
• Attenuation: 2.8 dB/km @ 850 nm, 1.0 dB/km @ 1300 nm
• Bandwidth (OFL): 1500 MHz·km @ 850 nm, 500 MHz·km @ 1300 nm
• Operating temperature: -10 to 60 °C

Tips

For best results, inspect and clean LC connectors before installation. Use cable management accessories to maintain the minimum bend radius and prevent signal loss.
