SHIVERPEAKS Cable de conexión SAT 3,75 m conector F a coaxial IEC 75 Ohm blanco (80094-96-CP)

For satellite and digital TV installations where signal integrity cannot be compromised, this SHIVERPEAKS SAT connection cable delivers professional-grade performance in a ready-to-use length. Unlike generic coaxial cables with flimsy shielding, the 80094-96-CP features double shielding with over 90 dB effectiveness, ensuring crisp DVB-S, DVB-T2, and DVB-C reception even in electrically noisy environments. The 75-ohm impedance is precisely matched to broadcast standards, while nickel-plated F-plug and IEC connectors resist corrosion and maintain tight contact over repeated connections.

Highlights

• Double-shielded coaxial construction with >90 dB shielding effectiveness for interference-free signal transfer
• Nickel-plated F-plug (male) to IEC coaxial plug (male) connectors for secure, low-loss connections
• 75-ohm impedance and 0–2400 MHz frequency range support satellite, terrestrial, and cable TV
• Copper-clad steel inner conductor combines strength with excellent signal conductivity
• Durable white PVC jacket with 6 mm outer diameter for easy routing and long service life

In daily use

At 3.75 metres, this cable bridges the gap between wall outlets, satellite receivers, and TV tuners without excess slack. The flexible yet robust PVC jacket resists kinking and abrasion, making it suitable for both fixed installations and temporary setups. The F-plug screws on securely to LNB outputs or wall plates, while the IEC connector fits standard receiver inputs. Whether you are upgrading an existing SAT system or setting up a new DVB-T2 antenna, the consistent 75-ohm impedance ensures minimal signal loss across the entire frequency band.

Full specifications

• Cable type: Coaxial cable
• Connector A: F-plug male
• Connector B: Coaxial plug male (IEC male)
• Cable length: 3.75 m
• Impedance: 75 Ohm
• Shielding type: Double shielded
• Shielding effectiveness: >90 dB
• Inner conductor material: Copper clad steel (CCS)
• Outer jacket material: PVC
• Cable colour: White
• Outer cable diameter: 6 mm
• Contact plating: Nickel-plated
• Supported applications: SAT, DVB-T2, DVB-C
• Frequency range: 0 - 2400 MHz

Final note

When signal quality matters, trust a cable built to broadcast standards. The SHIVERPEAKS 80094-96-CP combines premium shielding, precise impedance, and corrosion-resistant connectors to keep your TV reception sharp and reliable for years.
