Wirewin NVL9 SAI versión 19 pulgadas 1U Rackmount PDU, 9 salidas IEC C13, entrada IEC C14, 10A, negro

The SLIM WIREWIN NVL9 USV Version is a 19-inch rackmount power distribution unit engineered specifically for UPS systems, server racks, and network cabinets. It consolidates nine IEC C13 outlets into a single 1U housing, eliminating cable clutter while keeping connected equipment within easy reach of a protected power source.

Highlights

• 9 IEC C13 outlets for powering servers, switches, and peripherals
• IEC C14 input with 2.0 m cable for flexible connection to UPS or wall outlet
• Integrated illuminated master switch and circuit breaker for overload protection
• Anodized aluminum/steel housing in black for durability and heat dissipation
• 230 V AC, 10 A, 2300 W maximum load capacity

In daily use

Mount the NVL9 in a standard 19-inch rack and connect it to a UPS or mains supply. The front-facing outlets provide convenient access for equipment power cords, while the master switch allows you to cut power to all connected devices at once. The built-in circuit breaker trips if the total current exceeds 10 A, protecting both the PDU and downstream equipment.

Full specifications

• Product type: Power Distribution Unit (PDU)
• Mounting: 19-inch rackmount, 1U
• Outlets: 9x IEC C13
• Input plug: IEC C14
• Nominal input voltage: 230 V AC
• Maximum current: 10 A
• Maximum power: 2300 W
• Input cable length: 2.0 m
• Housing material: Anodized aluminum / steel
• Colour: Black
• Master switch: Yes, illuminated
• Overload protection: Integrated circuit breaker
• Surge protection: No
• Operating temperature: 0 °C to 45 °C
• Certifications: CE, RoHS

Final note

The NVL9 USV Version is a straightforward, no-frills PDU for installations where reliable power distribution is more important than monitoring or remote control.
