Wirewin WCAB 600X600X16U Armario de red de montaje en pared 16U, 600x600 mm, paneles laterales desmontables, negro

The SLIM WIREWIN WCAB 600X600X16U is a 16U wall-mount network cabinet with a 600x600 mm footprint, built for tidy and secure installation of 19-inch equipment in space-constrained areas. Its one-piece welded steel frame and lockable removable side panels provide robust protection and easy access.

Advantages

The cabinet's 600 mm depth accommodates standard network switches, patch panels, and servers. The tempered glass front door allows visual monitoring of equipment status while keeping it secure. Removable, lockable side panels enable convenient installation and maintenance. Top and bottom cable entry points with brush strips help maintain a clean cable layout.

Suitable for

• Small to medium business network installations
• Wall-mounted IT enclosures in offices, retail, or industrial environments
• Organizing 19-inch rack-mount equipment such as switches, patch panels, and UPS units

Key specifications

• Rack units: 16U
• External dimensions: 600 mm width, 600 mm depth, 800 mm height
• Material: SPCC cold rolled steel with powder coating, black (RAL 9005)
• Front door: tempered glass, lockable
• Side panels: removable and lockable
• Load capacity: 60 kg static
• Ventilation: passive, fan cutouts on top panel
• IP protection class: IP20

Recommendations

For secure and organized network equipment mounting in limited spaces, the WCAB 600X600X16U offers a solid steel construction with convenient access and cable management features.
