EFB Elektronik Caja de pared 19 inch 21U Flat Pack, 600x600x1040mm, RAL7035 gris claro, acero, puerta de cristal de seguridad, con cerradura, carga 60kg, IP20

The EFB Elektronik 691721FGR.2 is a high-quality 19-inch wall mount enclosure designed for professional networking, telecommunications, and IT infrastructure applications. This flat pack enclosure offers 21U of rack space with a depth of 600 mm, making it ideal for housing servers, switches, patch panels, and other 19-inch rack-mountable equipment. The enclosure is constructed from durable steel with a powder-coated finish in RAL 7035 light grey, ensuring a sleek and professional appearance. The front door features safety glass, providing visibility while maintaining security with a lockable mechanism. Side panels are removable and lockable for easy access during installation and maintenance.

Advantages

This wall mount enclosure offers a cost-effective and space-saving solution for organizing and protecting your IT equipment. The flat pack design allows for easy transportation and self-assembly, reducing shipping costs and enabling quick on-site setup. The adjustable 19-inch mounting rails (front and rear) provide flexibility for equipment of varying depths. Cable entry points at the top and bottom with brush strips ensure tidy cable management, while passive ventilation slots maintain adequate airflow. With a load capacity of 60 kg, this enclosure can support a substantial amount of equipment.

Suitable for

• Networking and telecommunications installations
• IT infrastructure in offices, schools, and data closets
• Housing servers, switches, patch panels, and UPS systems
• Wall-mounted applications where floor space is limited

Key specifications

• Rack Standard: 19 inch
• Rack Units: 21U
• Installation Type: Wall Mount
• External Dimensions: 600 mm (W) x 600 mm (D) x 1040 mm (H)
• Colour: RAL 7035 (Light Grey)
• Material: Steel, powder-coated
• Door: Single front door with safety glass, lockable
• Side Panels: Removable, lockable
• Mounting Rails: Adjustable 19" profiles (front and rear)
• Cable Entry: Top and bottom with brush strips
• Ventilation: Passive ventilation slots
• Load Capacity: 60 kg
• Protection Class: IP20
• Packaging: Flat Pack (self-assembly required)

Recommendations

For optimal performance, ensure proper ventilation around the enclosure and use cable management accessories to maintain airflow. This enclosure is suitable for indoor use only. Assembly instructions are included; we recommend two people for assembly due to the size and weight of the components.
