SCOT BK-1200ZL2 escuadra de montaje para placa de anclaje EL-1200

The SCOT BK-1200ZL2 Mounting Bracket is a high-strength, surface-mount bracket designed specifically for the SCOT EL-1200 electromagnetic lock and similar 1200lb (545kg) EM locks. Crafted from anodized aluminum alloy, this bracket ensures secure and precise installation for inward-swinging doors in access control systems.

Advantages

This mounting bracket offers exceptional durability and corrosion resistance, making it ideal for indoor security applications. Its adjustable design allows for fine-tuning the armature plate position, ensuring optimal alignment and holding force. The included hardware (screws, washers, Allen key) simplifies installation.

Suitable for

• SCOT EL-1200 electromagnetic locks
• 1200lb (545kg) rated EM locks
• Inward-swinging wooden, metal, or glass doors (with appropriate accessories)
• Access control systems and security doors

Key specifications

• Bracket Type: ZL-Type Mounting Bracket
• Compatibility: SCOT EL-1200 and similar 1200lb EM locks
• Holding Force Rating: 1200 lbs (545 kg)
• Material: High-Strength Anodized Aluminum Alloy
• Finish: Anodized Silver
• Installation: Surface Mount
• Components: L-Bracket, Z-Bracket, Armature Plate Holder
• L-Bracket Dimensions: 250mm (L) x 48mm (W) x 28mm (H)
• Z-Bracket Dimensions: 180mm (L) x 48mm (W) x 48mm (H)
• Adjustability: Yes
• Corrosion Resistance: Yes
• Operating Environment: Indoor
• Color: Silver

Recommendations

For best results, ensure the door and frame are properly aligned before installation. Use the provided hardware and follow the manufacturer's instructions for secure mounting.
